Instructions for Installing the Drain Hose on the Kosmen Household Dehumidifier

A household dehumidifier helps control humidity effectively, protecting both your health and your furniture from mold and dampness. The device condenses moisture into a water tank, which can be emptied manually or through a continuous drain hose.

If you want to save time, you can connect the included continuous drain hose to the back of the unit and lead it to a drain point such as a floor drain or sink. The water will automatically flow out by gravity.

Drain Hose Position on Kosmen Dehumidifiers

For all Kosmen household dehumidifier models, the drain outlet is located at the back of the unit. This consistent design makes it easy for users to operate regardless of the model they are using. To install the continuous drain hose, follow the steps below:

Step 1. Locate the Drain Outlet

• All Kosmen dehumidifier models have a drain outlet positioned at the back of the unit.
• Gently rotate the unit to clearly see this position. For models with a protective cover, remove it before attaching the hose.

Step 2. Connect the Drain Hose to the Outlet

• Use the flexible hose included with the unit (or a compatible 12 mm extension hose available at hardware stores).
• Insert the hose firmly into the drain outlet.
• Make sure the hose fits tightly and securely to prevent leakage.

Guide to Installing the Drain Pipe for Household Dehumidifier

Step 3. Position the Other End of the Hose

• Place the other end of the hose into a floor drain, sink, or dedicated drainage pipe.
• Ensure the hose is positioned lower than the unit so that water can flow out naturally by gravity.

Notes for Installing the Drain Hose on Kosmen Dehumidifiers

To ensure the drainage system works effectively and safely during operation, please keep in mind the following important points:

• Position the hose lower than the outlet: Make sure the end of the hose is lower than the drain outlet at the back of the unit. This allows water to flow out naturally by gravity, preventing water from accumulating inside the machine.
• Avoid bends or kinks: Do not bend, twist, or sharply curve the hose, as blockages may occur and obstruct continuous water flow.
• Secure the hose connection: Firmly fix the other end of the hose to the drainage point (floor drain or sink) to prevent it from slipping out during operation, which could cause water leakage onto the floor.
• Protect the hose: Keep the hose away from chemicals, high temperatures, or direct sunlight, as these factors can reduce its durability over time. Ensure the hose is installed in a dry, cool place and protected from physical damage.
• Stable long-term operation: Using the continuous drainage option helps the Kosmen dehumidifier run more efficiently, especially in high-humidity environments or with frequent use. With its simple design, users can easily install the hose at home. Remember to follow these technical notes to ensure effective and long-lasting operation.
